DJI Mavic 3 Enterprise drone

The Mavic 3 Enterprise Series redefines the industry standard for small commercial drones. With a mechanical shutter, a 56x zoom camera, and an optional RTK module for centimeter precision, the Mavic 3E takes mapping and mission efficiency to a whole new level.



3903,18€ VAT icluded

Send quote request

Fill out this field
Please enter a valid email address.
Fill out this field
Fill out this field
20 + 14 = ?
Enter the equation result to proceed
You need to agree with the terms to proceed

DJI Mini 4 Pro is currently the most powerful DJI drone with a mini-sized camera. It combines impressive filming capabilities, omnidirectional obstacle detection, ActiveTrack 360° with the new Trace mode and FHD video transmission with a range of up to 10 km. This makes it an ideal choice for both professionals and novice users.

Technical specifications:
DRONE
Total weight
(with propellers)[1]
915 g (Mavic 3E)
Max. weight 1050 g
Dimensions Folded (without propellers): 221×96.3×90.3 mm)
Unfolded (without propellers): 347.5×283×107.7 mm
Diagonal 380.1 mm
Maximum rate of climb 6 m/s (Normal Mode)
8 m/s (Sport Mode)
Max. speed
falling
6 m/s (S Mode)
6 m/s (N Mode)
Max. flight speed (without wind) 15 m/s (N Mode)
Forward: 21 m/s, Sideways: 20 m/s, Reverse: 19 m/s (S Mode)[2]
Max. wind resistance 12 m/s[3]
Max. flight time (without wind) 45 min[4]
Max. hovering time (without wind) 38 min
Maximum flight distance 8 km (CE)
Maximum tilt angle 30° (N Mode)
35° (S Mode)
Maximum angular velocity 200°/s
GNSS GPS + Galileo + BeiDou + GLONASS (GLONASS is only supported when RTK module is enabled)
Hover Accuracy Vertical: ±0.1 m (with vision system); ±0.5 m (with GNSS); ±0.1 m (with RTK)
Horizontal: ±0.3 m (with vision system); ±0.5 m (with high precision positioning system); ±0.1 m (with RTK)
Operating temperature range -10° to 40° C
Internal memory None
Engine model 2008
Propeller model 9453F – Enterprise
Beacon Lighting Built into drone
WIDE-ANGLE CAMERA
Sensor 4/3 CMOS, Effective pixel number: 20 MP
Lens FOV: 84°
Format equivalent: 24 mm
Aperture: f/2.8 to f/11
Focus: 1 m to ∞
ISO range 100-6400
Shutter speed Electronic shutter: 8-1/8000 s
Mechanical shutter: 8-1/2000 s
Maximum image size DJI Mavic 3E: 5280×3956
Shooting modes Single shot mode: 20 MP
Burst mode: 20 MP
JPEG: 0.7/1/2/3/5/7/10/15/20/30/60s
JPEG+RAW: 3/5/7/10/15/20/30/60 sec
Smart low light photography: 20MP
Panorama: 20 MP (raw image)
Video resolution H.264
4K: 3840×2160@30fps
FHD: 1920×1080@30fps
Bitrate 4K: 130 Mbps
FHD: 70 Mbps
Supported file formats exFAT
Image format JPEG/DNG (RAW)
Video format MP4 (MPEG-4 AVC/H.264)
CAMERA WITH TELEPHONE
Sensor 1/2-inch CMOS, Effective pixel number: 12 MP
Lens FOV: 15°
Format equivalent: 162 mm
Aperture: f/4.4
Focus: 3 m to ∞
ISO range 100-6400
Shutter speed Electronic shutter: 8-1/8000 s
Maximum image size 4000×3000
Image format JPEG
Video format MP4 (MPEG-4 AVC/H.264)
Shooting mode Single photo mode: 12 MP
Burst mode: 12 MP
JPEG: 0.7/1/2/3/5/7/10/15/20/30/60s
JPEG+RAW: 3/5/7/10/15/20/30/60 sec
Smart Low Light Shooting: 12MP
Video resolution H.264
4K: 3840×2160@30fps
FHD: 1920×1080@30fps
Bitrate 4K: 130 Mbps
FHD: 70 Mbps
Digital zoom 8x (56x hybrid zoom)
GIMBAL
Type 3-axis (tilt, roll pan)
Mechanical operating range Tilt: -135° to 100°
Roll: -45° to 45°
Pan: -27° to 27°
Adjustment range Tilt axis: -90° to 35°
Pan: no scope
Maximum steering speed (tilt axis) 100°/s
Angular vibration range ±0.007°
OBSTACLE DETECTION SENSOR
Type Omnidirectional binocular vision system, supplemented with an infrared sensor located at the bottom of the drone.
Front Measuring range: 0.5-20 m
Detection range: 0.5-200 m
Effective detection speed: Flight speed ≤15m/s
FOV: Horizontal 90°, Vertical 103°
Rear Measuring range: 0.5-16 m
Effective detection speed: Flight speed ≤12m/s
FOV: Horizontal 90°, Vertical 103°
Side Measuring range: 0.5-25 m
Effective detection speed: Flight speed ≤15m/s
FOV: Horizontal 90°, Vertical 85°
Top Measuring range: 0.2-10 m
Effective detection speed: Flight speed ≤6m/s
FOV: Front and rear 100°, left and right 90°
Bottom Measuring range: 0.3-18 m
Effective detection speed: Flight speed ≤6m/s
FOV: front and rear 130°, left and right 160°
Working environment Forward, backward, sideways and up: Surface with clear structure and adequate lighting (lux >15)
Down: A surface with diffuse reflection of >20% (e.g. walls, trees, people) and adequate lighting (lux >15)
VIDEO TRANSMISSION
Video transmission system DJI O3 Enterprise
Live view quality Remote Control Preview: 1080p/30fps
Operating frequency [6] 2.400-2.4835 GHz
5.725-5.850 GHz
Maximum transmission distance (unobstructed, no interference) [7] CE: 8 km
Maximum transmission distance (with obstacles) [8] Strong interference (dense development, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC)
Medium disturbance (suburban areas, city parks, etc.): 3-6 km (CE/SRRC/MIC)
Low interference (open spaces, remote areas, etc.): 6-8 km (CE/SRRC/MIC)
Maximum download speed [9] 15 MB/s (with DJI RC Pro Enterprise)
Delays (depending on environmental conditions and mobile device) About 200 ms
Antennas 4 antennas, 2T4R
Transmit power (EIRP) 2.4 GHz: <20 dBm (CE/SRRC/MIC)
5.8 GHz: <30 dBm (SRRC), <14 dBm (CE)
DJI RC PRO ENTERPRISE CONTROL EQUIPMENT
Video transmission system DJI O3 Enterprise
Maximum transmission distance (unobstructed, no interference) [7] CE/SRRC/MIC: 8 km
Video transmission operating frequency [6] 2.400-2.4835 GHz
5.725-5.850 GHz
Antennas 4 antennas, 2T4R
Video transmitter power (EIRP) 2.4 GHz: <20 dBm (CE/SRRC/MIC)
5.8 GHz: <14 dBm (CE), <23 dBm (SRRC)
Wi-Fi protocol 802.11 a/b/g/n/ac/ax
2×2 MIMO Wi-Fi support
Wi-Fi frequency [6] 2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Wi-Fi Transmitter Power (EIRP) 2.4 GHz: <20 dBm (CE/SRRC/MIC)
5.1 GHz: <23 dBm (CE/SRRC/MIC)
5.8 GHz: <14 dBm (CE)
Bluetooth protocol Bluetooth 5.1
Bluetooth transmitter power (EIRP) < 10 dBm
Screen resolution 1920×1080
Screen size 5.5 inch
Frames per second (FPS) 60 fps
Brightness 1000 nits
Touch screen control 10-point multi-touch
Built-in battery Li-ion (5000 mAh @ 7.2 V)
Loading method Recommended charging with included DJI USB-C Power Adapter (100W) or 12V or 15V USB charger
Rated power 12 W
Memory Internal memory (ROM): 64 GB
Supports microSD card to increase capacity.
Loading time Approximately 1 hour 30 minutes (with included DJI USB-C Power Adapter (100W) charging the remote control only or with a 15V USB charger)
Approximately 2 hours (with 12V USB charger)
Approximately 2 hours 50 minutes (with the included DJI USB-C Power Adapter (100W) charging the drone and camera simultaneously)
Uptime about 3 hours
Video output port Mini-HDMI port
Operating temperature range 10° to 40° C
Storage temperature -30° to 60° C (within one month)
-30° to 45° C (one to three months)
-30° to 35° C (three to six months)
-30° to 25° C (over six months)
Charging temperature 5° to 40° C
Compatible DJI Drones [10] DJI Mavic 3E
DJI Mavic 3T
GNSS GPS+Galileo+GLONASS
Dimensions Compound antennas and unmounted apparatus rods:
183.27×137.41×47.6 mm (L×W×H)
Antennas deployed and apparatus sticks installed:
183.27×203.35×59.84 mm (L×W×H)
Weight about 680 g
Model RM510B
DATA STORAGE
Supported memory cards Drone:
U3/Class10/V30 or higher card required. Recommended microSD cards are listed below.
Recommended microSD cards Control equipment:
SanDisk Extreme PRO 64GB V30 A2 microSDXC
SanDisk High Endurance 64GB V30 microSDXC
SanDisk Extreme 128GB V30 A2 microSDXC
SanDisk Extreme 256GB V30 A2 microSDXC
SanDisk Extreme 512GB V30 A2 microSDXC
Lexar 667x 64GB V30 A2 microSDXC
Lexar High-Endurance 64GB V30 microSDXC
Lexar High-Endurance 128GB V30 microSDXC
Lexar 667x 256GB V30 A2 microSDXC
Lexar 512GB V30 A2 microSDXC
Samsung EVO Plus 64GB V30 microSDXC
Samsung EVO Plus 128GB V30 microSDXC
Samsung EVO Plus 256GB V30 microSDXC
Samsung EVO Plus 512GB V30 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas React Plus 128GB V90 A1 microSDXC
Drone:
SanDisk Extreme 32GB V30 A1 microSDHC
SanDisk Extreme PRO 32GB V30 A1 microSDHC
SanDisk Extreme 512GB V30 A2 microSDXC
Lexar 1066x 64GB V30 A2 microSDXC
Kingston Canvas Go! Plus 64GB V30 A2 microSDXC
Kingston Canvas React Plus 64GB V90 A1 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas React Plus 128GB V90 A1 microSDXC
Kingston Canvas React Plus 256GB V90 A2 microSDXC
Samsung PRO Plus 256GB V30 A2 microSDXC
DRONE BATTERY
Capacity 5000 mAh
Standard voltage 15.4 V
Maximum charging voltage 17.6 V
Cell type LiPo 4S
Chemical composition LiCoO2
Energy 77 Wh
Weight 335.5 g
Charging temperature 5° to 40° C
CHARGER
Input 100-240 V (AC power supply), 50-60 Hz, 2.5 A
Output power 100 W
Output Maximum 100W (total)
When both ports are used, the maximum output power of each interface is 82W, and the charger will dynamically allocate the output power of the two ports according to the load power.
CHARGING HUB
Input USB-C: 5-20 V, 5.0 A
Output Battery port: 12-17.6V, 8.0A
Rated power 100 W
Loading method Three batteries charged individually
Charging temperature range 5° to 40° C
OPTIONAL RTK MODULE
Dimensions 50.2×40.2×66.2 mm (L×W×H)
Weight 24±2 g
Interface USB-C
Power about 1.2 W
RTK positioning accuracy RTK Fix:
Horizontal: 1 cm + 1 ppm; Vertical: 1.5 cm + 1 ppm
OPTIONAL SPEAKER
Dimensions 114.1×82.0×54.7 mm (length×width×height)
Weight 85±2 g
Interface USB-C
Rated power 3 W
Maximum intensity [11] 110 dB @ 1 m
Effective transmit distance [11] 100 m @ 70 dB
Bitrate 16 Kbps/32 Kbps
Operating temperature range 10° to 40° C
